Residential Loop Regenerator

Loop Regenerator Range 5,10,15 & 20kW

Regenerative by design –

The Loop Regenerator is an intelligent, battery-based uninterrupted power supply (UPS) that auto-detects demand and automatically recharges with its unique integrated IP-protected technique to keep your appliances running as needed. As such, Loop Regenerators afford you a carefree turnkey stand-alone, Off-Grid, zero-emissions operation to satisfy all your domestic energy demands. The compact, minimalist all-in-one design makes for easy installation and versatile mounting options for indoor or outdoor spaces.

Applications

Houses

Small Commercial

Apartments

Homesteads

Technology Comparision

*Value Proposition: to equal the output of our 15kW Loop Regenerator you would require 2x Powerwall systems, Solar Roof or panels, and/or the grid connection for backup energy, whereas the Loop Regenerator offers a decentralized stand-alone continuous power supply.

Measure	Loop Regenerator	Solar + Batteries/ PowerWall	Wind + Batteries	Grid
Renewable	Yes	Yes	Yes	No
Pollution	Low	Low	Low	High
Ecological footprint	Small	Medium	Small	Large
Reliability	High	Low	Low	High
Cost (unit)*	Low	Moderate	Moderate	Low
Cost (operation)	Low	Low	Low	High

Generation specifications

The (5/10/15/20)kWh Loop Regenerator range offers unparalleled power specifications for autonomous Off-Grid residential energy solutions.

15/22/30/45A

Continuous AC current

30/45/60/90A

Maximum AC current

-20°C to 50°C

Operating temperature

W875xD705xH1755mm

Dimensions

Except for the 5kW system measuring

W875xD705xH1450mm

5/10/15/20kWh

Energy Capacity

50/60hz

AC output frequency

< 3%

Total harmonic distortion

320-450kg

Unit weight

(Including Batteries)

2.5/5/10/15kW

Continuous Power

110-220V

Rated voltage

93%

Inverter efficiency

Discover your perfect energy solution

5kW Loop Regenerator

Energy solution for small apartment living and energy light residentials

R139,000 excl VAT

Order now

10kW Loop Regenerator

Energy solution for apartment living, small residentials, micro commercial properties

R179,000 excl VAT

Order now

15kW Loop Regenerator

Energy solution for medium to large residentials and small commercial properties

R189,000 excl VAT

Order now

20kW Loop Regenerator

Energy solution for large residentials and medium scale commercial properties

R209,000 excl VAT

Order now

Battery

Continuous regulated power

Battery charge/discharge efficiency – 97.6% / 96%

Nominal DC Voltage – 12V

Battery Capacity – 460/690/920/920 Ah

Maximum Discharge Current – 90A

Installation

Energy independence in 1 hour

Its small dimensions make it ideal for an indoor fit. Designed for indoors/garage, basement, floor or wall mounted. Can also be fitted in roof or secured outdoors in moderate climates as per most battery-based technologies. The unit itself is low voltage DC and only needs to be grounded, not earthed. All the components are grounded within the unit, by means of a grounding bar. The inverter switches DC to 220V AC for your household supply and a live, neutral and earth comes from the inverter and is connected to the house’s DB Board. Integrated inverter and systems controller; Water and dust resistant.

Security

Tamperproof technology

Comes as a sealed unit with an embedded anti-theft system. The moment the device is tampered with, we get an instant notification and the controller is destroyed, disabling operation with tracking activated via local security partners.

Warranties

10 year warranty on IP-Protected Production Unit. 5 year warranty on all other components, including batteries and inverters as per manufacturer specifications dependent on type and availability at time of order.

Compliance

Energy compliant technology

The ZADEUS Loop Regenerators meet all local safety standards. Embedded overload safety setting. The earth protection on the DB, as per regulations, protects the house’s electrical system.
